SmartScope® Flash™ systems are the best choice in automatic general purpose dimensional measurement. A high quality, 12:1 zoom lens calibrates itself at every magnification change for consistent measurement accuracy. Innovative solid state illumination sources, color camera and Measure-X® metrology software make every Flash model a powerful video measuring system. Every Flash model is multisensor capable, supporting touch probe, laser scanner and micro-probes.
Each SmartScope Flash can be easily customized with powerful 3-D measurement options, such as MeasureMind® 3-D MultiSensor software, rotary indexers and much more.
Buy ATN Smart HD an Ultra HD Optics. Newest Digital Night Vision technology inside the binoculars, scopes, monoculars. Night Vision, Thermal Imaging and Day Time hunting optics. OGP Smartscope Features. All sensors are installed during production with the system and integrated with both the hardware and the software. All sensors are also calibrated together and available for use at all times during a measurement job. Types of Sensors. QVI's SmartScope® SP systems are designed for optimum scanning probe performance. Starting with a rigid base structure, the system mechanics are designed to optimize dynamic data acquisition critical to scanning probe performance. SmartScope SP systems feature ultra-stiff Z-axis motion, and one independent motion axis that carries the part. These characteristics eliminate common mechanical. The SmartScope ZIP® 450 is a floor standing digital measuring system offering video and multisensor measurement for large parts and offers Cross customers an excellent option for measuring large parts with speed and efficiency. This OGP system has a reputation for extreme reliability and proven metrological performance.
SmartScope Flash Models
SmartScope® Flash™ 200 (200 x 200 x 150 mm) – The smallest member of the Flash family of systems is a full-featured automatic measurement system. Innovative design features of “elevating bridge” and an embedded computer mean the system takes up little space on a benchtop while providing an ample measuring range and extensive measurement capabilities. It also has patented innovations that let users do more, faster. The computer controlled LED array backlight tracks X-axis motion of the optics with no moving parts. SmartRing™ light is standard for the ultimate flexibility in surface illumination.
SmartScope® Flash™ 250 (300 x 150 x 200 mm) – A compact machine designed for easy access to the XY stage for maximum fixturing flexibility. Its large 300 mm X travel makes it the system of choice for measuring critical dimensions of long parts on a benchtop machine. Its heavy cast base and rigid steel column provide metrology integrity so accuracy can be maintained in real world environments. Like all Flash systems, it is equipped with OGP® Measure-X® metrology software and 12:1 AccuCentric® zoom optics. It’s ideal for a wide variety of manufacturing industries including metalworking, plastics, biomedical, electronics, automotive, aerospace and more.
SmartScope® Flash™ 302 (300 x 300 x 250 mm) – One of the most versatile benchtop systems OGP offers. With an expansive Z-axis of 250 mm (10 in.) to accommodate large parts, it combines state-of-the-art video and autofocus to deliver high productivity. Add optional through-the-lens (TTL) laser, touch probe or micro-probe to configure a highly capable multisensor system. It contains a unique “elevating bridge” design and axial straightness and perpendicularity are built in to meet stringent volumetric specifications. A high-quality auto calibrating AccuCentric® 12:1 zoom lens provides excellent optical performance over its entire range. It also comes standard with a TTL coaxial illuminator and patented LED SmartRing™ light.
SmartScope® Flash™ 500 (Contact us for XYZ Stage Travel details) – Offers all the great Flash features and performance in a large, travel bridge-design system. Parts move on a precision DC motor-driven Y-axis stage while the optics assembly travels in the X-axis across a stable bridge cross member. This design assures rapid, smooth part translation and robust measurement performance. An extended Y-axis travel of 610 mm is optional and either 300 mm or 400 mm extended Z-axis travel is available.
Smart Gun Scope
SmartScope® Flash™ 635 (635 x 635 x 200 mm) – Provides measurement speed and stability. Its unique carbon fiber composite X-axis beam exhibits superior noise-dampening characteristics, while its light weight contributes to measurement speed. While the instrument head moves in the X, Y and Z axes, the part being measured remains stationary.
